Overview
The Del Morino RES10 is a compact PTO-driven backhoe designed for tractors from 10–35 HP. Manufactured in Italy by Del Morino — a company with over 140 years of agricultural equipment manufacturing — the RES10 features an independent gear-driven hydraulic system, six hydraulic cylinders, and a 1450mm maximum digging depth. Suited to lifestyle blocks, orchards, vineyards, small farms, and contractors needing compact excavator capability without a dedicated machine.
Features & Benefits
- Independent PTO-driven hydraulic system – consistent performance regardless of tractor hydraulic capacity
- Six hydraulic cylinders – full control of boom, dipper, bucket, and swing
- 13-litre dedicated hydraulic oil reservoir – self-contained system, no tractor hydraulics required
- 1450mm maximum digging depth – suitable for drainage, water lines, and conduit trenches
- Category 1 three-point linkage – fits most compact tractors
- Standard stabiliser kit – keeps the tractor secure during digging
- Adjustable raised operator's seat – comfortable working position with good visibility
- 250mm digging bucket included as standard
- Compact overall width of 1100mm – suitable for tight working areas
- Italian-manufactured heavy-duty steel construction for long service life
Specifications
| Specification | Value |
|---|---|
| Recommended Tractor Power | 10–35 HP |
| PTO Speed | 540 RPM |
| Three-Point Linkage | Category 1 |
| Hydraulic System | Independent PTO driven |
| Hydraulic Cylinders | 6 |
| Hydraulic Oil Capacity | 13 litres |
| Maximum Digging Depth | 1,450mm |
| Standard Bucket Width | 250mm (EXL25) |
| Overall Width | 1,100mm |
| Weight | 246kg |
| Origin | Italy |
Specifications supplied by the manufacturer.
Best For
- Digging drainage trenches
- Water pipe and electrical conduit installation
- Tree planting and fence post holes
- Landscaping and garden development
- Orchard and vineyard maintenance
- General farm and lifestyle block earthworks
Compatibility
- Tractor HP Range: 10–35 HP
- Hitch Type: Category 1 three-point linkage
- Drive: PTO (540 RPM)
What's Included
- Del Morino RES10 backhoe
- PTO shaft
- PTO-driven hydraulic pump
- Independent hydraulic oil tank
- Six hydraulic cylinders
- Adjustable raised operator's seat
- Standard stabiliser kit
- 250mm digging bucket (EXL25)
Warranty & Support
Supplied by Implements Direct as an authorised Del Morino dealer. Backed by a 24 month warranty with spare parts and technical support available locally.
